Pipes and Redirection

Part of Essentials

This article assumes you're comfortable with basic commands and command chaining (&&, ||). Pipes are related but different — they connect command output to command input, not just sequence execution.

The most powerful Linux one-liners you'll ever see don't use a single complex command. They use simple commands connected together. cat access.log | grep "500" | awk '{print $1}' | sort | uniq -c | sort -nr | head -10 — that's ten minutes of investigation distilled to one line, and each part is a simple tool you already know.

That's the Unix philosophy in action: programs that do one thing well, connected by pipes. This article shows you how to connect them.

---

Where You've Seen This

If you've used PowerShell, you know pipes — Get-Process | Where-Object CPU -gt 10 | Sort-Object CPU -Descending. The Linux version works the same way conceptually, but passes plain text instead of objects. That difference matters: Linux pipelines are more composable (any tool can talk to any other tool), but you work with structured text rather than typed objects.

If you've built ETL pipelines, data workflows, or streaming architectures — Kafka, Spark, Logstash — the stdin/stdout model is the same idea at shell scale. Data flows from source through transformations to sink. Each command is a transform.

Redirection (>, >>, 2>) is the command-line equivalent of writing to a file in any language. You've done this before; the Linux operators are just a more concise syntax.

---

Standard Streams: The Foundation

Every process in Linux has three data channels open by default:

graph LR
    STDIN["📥 stdin (0)\nStandard Input\n← Keyboard or pipe"] --> PROCESS["⚙️ Command\nor Process"]
    PROCESS --> STDOUT["📤 stdout (1)\nStandard Output\n→ Screen or redirect"]
    PROCESS --> STDERR["⚠️ stderr (2)\nStandard Error\n→ Screen or redirect"]

    style STDIN fill:#2d3748,stroke:#63b3ed,stroke-width:2px,color:#fff
    style PROCESS fill:#d69e2e,stroke:#cbd5e0,stroke-width:2px,color:#000
    style STDOUT fill:#2d3748,stroke:#68d391,stroke-width:2px,color:#fff
    style STDERR fill:#2d3748,stroke:#fc8181,stroke-width:2px,color:#fff

Stream	Number	Default	What Goes Here
stdin	0	Keyboard	Input to commands
stdout	1	Terminal	Normal output
stderr	2	Terminal	Error messages

By default, stdout and stderr both print to your terminal mixed together. Redirection and pipes give you control over each stream separately.

---

Redirection: To and From Files

Redirection changes where a stream goes — from the terminal to a file, or from a file to a command's input.

• Output Redirection (>)

  ---

  Why it matters: Capture command output to a file for logging, later processing, or sharing with others.

  Redirect stdout to a File

  ls -lh /var/log/ > filelist.txt     # create/overwrite
  df -h > disk-report.txt


  > Overwrites Without Warning

  > will silently overwrite an existing file. There's no confirmation. If report.txt existed, it's gone.

  To protect against this in interactive sessions:

  Prevent Overwrite with noclobber

  set -o noclobber    # add to ~/.bashrc
  ls > existing.txt   # now fails with "cannot overwrite existing file"
  ls >| existing.txt  # force overwrite when noclobber is set


• Append Redirection (>>)

  ---

  Why it matters: Add to an existing file without overwriting it. The essential operator for log files and accumulating data.

  Append to a File

  echo "Deployment started at $(date)" >> deploy.log
  df -h >> disk-history.txt   # build a history over time

  # Running multiple commands and collecting all output
  echo "=== $(date) ===" >> report.txt
  uptime >> report.txt
  free -h >> report.txt
  df -h >> report.txt


• Input Redirection (<)

  ---

  Why it matters: Feed a file into a command's stdin instead of typing. Less common in interactive use, but appears in scripts.

  Redirect File to stdin

  sort < names.txt          # sort the contents of names.txt
  wc -l < access.log        # count lines in access.log
  mysql -u root -p mydb < schema.sql   # feed SQL to mysql


• stderr Redirection (2>)

  ---

  Why it matters: Error messages and normal output are separate streams. When you redirect with >, errors still print to the terminal. Use 2> to capture them separately.

  Redirect stderr

  find / -name "hosts" 2>/dev/null      # discard errors, keep results
  find / -name "hosts" 2>errors.txt     # save errors to file
  command > output.txt 2> errors.txt    # separate stdout and stderr
  command > all.txt 2>&1               # (1)! combine both to one file


  1. 2>&1 redirects stderr (2) to wherever stdout (1) is currently going. Order matters: > all.txt 2>&1 works; 2>&1 > all.txt does not (the latter redirects stderr to the terminal, then redirects stdout to the file).

Combining Redirections

Multiple Redirections in Practice

# Capture output to file AND show it on screen simultaneously
# (tee reads stdin and writes to both stdout and a file)
find /var/log -name "*.log" | tee found-logs.txt

# Run a long job, save output, discard errors
./long-running-script.sh > results.txt 2>/dev/null

# Save both stdout and stderr to the same file
./deployment.sh > deploy.log 2>&1

# Save stderr to one file, stdout to another
./script.sh > output.log 2> errors.log

Here Documents and Here Strings

For feeding multi-line input to commands:

Here Documents

# Feed multiple lines to a command
cat << EOF > /etc/myapp/config.conf
[database]
host = db-prod-01
port = 5432
name = myapp_db
EOF

# Common for creating config files in scripts
sudo tee /etc/nginx/sites-available/myapp << EOF
server {
    listen 80;
    server_name myapp.example.com;
    root /var/www/myapp;
}
EOF

Here String (<<<)

# Feed a single string to stdin
grep "pattern" <<< "string to search in"

# Practical: feed a variable to a command expecting stdin
base64 <<< "encode this text"

---

Pipes: Command to Command

A pipe (|) takes the stdout of the left command and feeds it as stdin to the right command. No intermediate file, no waiting — it's streaming.

Your First Pipeline

ls -lh /var/log/ | less
# ls outputs the directory listing
# | sends it to less
# less lets you scroll through it

Building Pipelines

Pipelines chain as many commands as you need:

Growing a Pipeline

# Start simple
cat /var/log/nginx/access.log

# Filter to 500 errors only
cat /var/log/nginx/access.log | grep " 500 "

# Extract just the IP addresses
cat /var/log/nginx/access.log | grep " 500 " | awk '{print $1}'

# Sort them
cat /var/log/nginx/access.log | grep " 500 " | awk '{print $1}' | sort

# Count occurrences of each IP
cat /var/log/nginx/access.log | grep " 500 " | awk '{print $1}' | sort | uniq -c

# Sort by count, most first
cat /var/log/nginx/access.log | grep " 500 " | awk '{print $1}' | sort | uniq -c | sort -nr

# Show only the top 10
cat /var/log/nginx/access.log | grep " 500 " | awk '{print $1}' | sort | uniq -c | sort -nr | head -10

This is how investigation pipelines get built — one stage at a time, checking the output at each step.

The Essential Pipeline Tools

These commands exist primarily to work within pipelines:

• grep — Filter Lines

  ---

  Filter a stream to only lines matching a pattern. Covered in depth in the grep article.

  grep in Pipelines

  journalctl | grep "Failed"
  ps aux | grep nginx
  cat /etc/passwd | grep -v "nologin"    # exclude service accounts


• sort — Sort Lines

  ---

  Sort lines alphabetically or numerically.

  sort in Pipelines

  cat names.txt | sort              # alphabetical
  du -sh /var/* | sort -hr          # human-readable, largest first
  cat numbers.txt | sort -n         # numeric sort
  cat file.txt | sort -u            # sort and remove duplicates


• uniq — Remove Duplicates / Count

  ---

  Remove consecutive duplicate lines, or count their occurrences. Works best after sort.

  uniq in Pipelines

  cat file.txt | sort | uniq               # unique lines only
  cat file.txt | sort | uniq -c            # count occurrences
  cat file.txt | sort | uniq -d            # only lines that appear more than once


• wc — Count

  ---

  Count lines, words, or characters.

  wc in Pipelines

  ls /etc | wc -l                     # how many files in /etc?
  cat access.log | grep "404" | wc -l  # how many 404 errors?
  cat file.txt | wc -c                 # how many bytes?


• awk — Extract Fields

  ---

  Extract specific columns from structured text. The most powerful field processor in the pipeline toolkit.

  awk in Pipelines

  ps aux | awk '{print $1, $2}'         # print user and PID columns
  df -h | awk '{print $1, $5}'          # filesystem and usage %
  cat /etc/passwd | awk -F: '{print $1, $3}'  # username and UID


• cut — Extract Columns

  ---

  Extract specific columns or character positions from fixed-format output.

  cut in Pipelines

  cat /etc/passwd | cut -d: -f1         # extract first field (username)
  cat /etc/passwd | cut -d: -f1,3       # username and UID
  ls -l | cut -c1-10                    # first 10 characters of each line


• tee — Split Output

  ---

  Write to a file AND pass through to the next pipe. Essential when you want to save intermediate results.

  tee in Pipelines

  find /var/log -name "*.log" | tee found-logs.txt | wc -l
  # saves the file list AND prints the count

  command | tee output.txt | grep "ERROR"
  # saves everything to output.txt, passes only errors downstream


• head / tail — Limit Output

  ---

  Take only the first or last N lines. Ubiquitous at the end of pipelines.

  head and tail in Pipelines

  ps aux | sort -k3 -nr | head -5      # top 5 CPU consumers
  ls -lt /var/log/ | head -10          # 10 most recently modified logs
  cat access.log | tail -100           # last 100 lines


stderr in Pipelines

A critical detail: pipes only carry stdout. stderr bypasses the pipe and goes directly to the terminal.

Stderr Bypasses Pipes

find / -name "*.conf" | wc -l
# Errors print to screen; only successful results go to wc

To include stderr in a pipeline:

Including stderr in Pipelines

find / -name "*.conf" 2>&1 | wc -l    # count everything including error lines
find / -name "*.conf" 2>/dev/null | wc -l   # suppress errors, count only results

---

Real-World Pipeline Patterns

Log AnalysisProcess InvestigationDisk Space InvestigationConfig File Work

Find the most common errors in the past hour:

Log Analysis Pipeline

# What IP addresses are causing the most 404s?
grep " 404 " /var/log/nginx/access.log \
  | awk '{print $1}' \
  | sort | uniq -c \
  | sort -nr \
  | head -10

# How many errors per hour in the last day?
journalctl --since "24 hours ago" --until now \
  | grep -i "error" \
  | awk '{print $1, $2, substr($3,1,2)}' \
  | sort | uniq -c

Find what's consuming resources:

Process Investigation Pipeline

# Top 5 memory consumers (human-readable)
ps aux --sort=-%mem | head -6

# All processes owned by www-data
ps aux | grep "^www-data"

# Find processes listening on a port
ss -tlnp | grep ":8080"

# How many connections per state?
ss -s | grep "TCP:"

Find what's eating disk:

Disk Analysis Pipeline

# Largest directories in /var
du -sh /var/* 2>/dev/null | sort -hr | head -10

# Largest files anywhere on the system
find / -type f -size +100M 2>/dev/null \
  | xargs ls -lh 2>/dev/null \
  | sort -k5 -hr \
  | head -10

# Which log files grew today?
find /var/log -name "*.log" -newer /var/log -type f \
  | xargs ls -lh 2>/dev/null \
  | sort -k5 -hr

Process configuration files:

Config Processing Pipeline

# Find all uncommented settings in a config file
grep -v "^#" /etc/ssh/sshd_config | grep -v "^$"

# Find all unique setting names
grep -v "^#" /etc/ssh/sshd_config \
  | grep -v "^$" \
  | awk '{print $1}' \
  | sort -u

# Check if a setting is enabled
grep -v "^#" /etc/ssh/sshd_config | grep "PermitRootLogin"

---

Quick Reference

Redirection Operators

Operator	What It Does	Example
>	Redirect stdout to file (overwrite)	ls > files.txt
>>	Redirect stdout to file (append)	echo "line" >> log.txt
<	Redirect file to stdin	sort < names.txt
2>	Redirect stderr to file	find / 2>/dev/null
2>&1	Redirect stderr to stdout	command > all.txt 2>&1
&>	Redirect both stdout and stderr	command &> all.txt
\|	Pipe stdout to next command	ls \| grep ".conf"
\| tee	Write to file and pass through	cmd \| tee file.txt \| wc -l

Pipeline Toolkit

Command	What It Does in Pipelines
grep pattern	Keep only lines matching pattern
grep -v pattern	Remove lines matching pattern
sort	Sort lines alphabetically
sort -n	Sort numerically
sort -hr	Sort human-readable sizes, largest first
uniq	Remove consecutive duplicates
uniq -c	Count occurrences
wc -l	Count lines
head -N	Keep first N lines
tail -N	Keep last N lines
awk '{print $N}'	Extract Nth field
cut -d: -f1	Extract field by delimiter
tee file.txt	Write to file and pass through

---

Practice Exercises

Exercise 1: Build a Log Analysis Pipeline

Using /var/log/auth.log (or /var/log/secure on RHEL), build a pipeline that:

1. Shows only lines containing "Failed"
2. Extracts the source IP address (the IP after "from" in the line)
3. Counts how many failed attempts per IP
4. Sorts by count, highest first
5. Shows the top 5 offenders

Solution

Log Analysis Pipeline

grep "Failed" /var/log/auth.log \
  | awk '/from/{print $(NF-3)}' \
  | sort \
  | uniq -c \
  | sort -nr \
  | head -5

The awk pattern prints the field 3 from the end (NF-3) — on typical auth.log "Failed password" lines, this is the IP address.

Exercise 2: Redirect and Tee

Run a disk space analysis (du -sh /var/* 2>/dev/null) that:

1. Saves the complete output to /tmp/disk-report.txt
2. Simultaneously shows only entries larger than 1GB on the terminal

Solution

tee with Filtering

du -sh /var/* 2>/dev/null | tee /tmp/disk-report.txt | grep "^[0-9]*G"

tee saves everything to the file; the pipe after tee sends the same data to grep, which filters for lines starting with a size in gigabytes.

Exercise 3: Separate stdout and stderr

Run find / -name "sshd_config" and:

1. Save only the successful results (stdout) to /tmp/found.txt
2. Discard all "Permission denied" errors (stderr)
3. Print the count of found files to the terminal

Solution

Separate Streams

find / -name "sshd_config" 2>/dev/null > /tmp/found.txt
wc -l < /tmp/found.txt

# Or in one pipeline:
find / -name "sshd_config" 2>/dev/null | tee /tmp/found.txt | wc -l

---

Quick Recap

• Three streams: stdin (0), stdout (1), stderr (2) — redirect each independently
• > overwrites; >> appends — the most common mistake is using > when you meant >>
• 2>/dev/null — silence errors; ubiquitous in find and other commands that hit permission-denied directories
• 2>&1 — merge stderr into stdout; essential when capturing all output to a file
• | pipes only stdout — to include stderr, add 2>&1 before the pipe
• Build pipelines incrementally — add one stage at a time, verify output, then extend
• Core toolkit: grep, sort, uniq -c, wc -l, head, tail, awk, tee

---

Further Reading

Command References

• man bash — the "Redirection" section covers every redirect operator
• man tee — the tee command in detail
• man awk — the full awk reference (also man gawk for GNU awk)
• man sort — sort options including locale-aware and stable sorting
• man uniq — uniq options

Deep Dives

• The Art of Command Line: Data Wrangling — practical pipeline patterns
• Bash Redirections Cheat Sheet — Bash Hackers Wiki on redirection
• Unix Philosophy — why pipes exist and why they work

Official Documentation

• GNU Coreutils Manual — sort, uniq, wc, tee, head, tail
• GNU Bash Manual: Redirections — complete redirect reference

---

What's Next?

Pipes flow data between commands, and the most common thing you'll do with that data is search it. grep is the workhorse of Linux text processing — and it deserves its own deep dive.

Head to grep to learn regular expressions, recursive searching, context flags, and the patterns that turn grep from a simple filter into a powerful investigation tool.
