Pipes and Redirection🔗

Part of a deep dive and a pathway: Text & Pipelines Debugging With Nothing But a Terminal

Consult the map

Prerequisites

This article assumes you're comfortable with basic commands and command chaining (&&, ||). Pipes are related but different — they connect command output to command input, not just sequence execution.

The most powerful Linux one-liners you'll ever see don't use a single complex command. They use simple commands connected together. cat access.log | grep "500" | awk '{print $1}' | sort | uniq -c | sort -nr | head -10 — that's ten minutes of investigation distilled to one line, and each part is a simple tool you already know.

That's the Unix philosophy in action: programs that do one thing well, connected by pipes. This article shows you how to connect them.

Where You Might Have Seen This🔗

If you've used PowerShell, you know pipes — Get-Process | Where-Object CPU -gt 10 | Sort-Object CPU -Descending. The Linux version works the same way conceptually, but passes plain text instead of objects. That difference matters: Linux pipelines are more composable (any tool can talk to any other tool), but you work with structured text rather than typed objects.

If you've built ETL pipelines, data workflows, or streaming architectures — Kafka, Spark, Logstash — the stdin/stdout model is the same idea at shell scale. Data flows from source through transformations to sink. Each command is a transform.

Redirection (>, >>, 2>) is the command-line equivalent of writing to a file in any language. You've done this before; the Linux operators are just a more concise syntax.

Standard Streams: The Foundation🔗

Every process in Linux has three data channels open by default:

graph LR
    STDIN["📥 stdin (0)\nStandard Input\n← Keyboard or pipe"] --> PROCESS["⚙️ Command\nor Process"]
    PROCESS --> STDOUT["📤 stdout (1)\nStandard Output\n→ Screen or redirect"]
    PROCESS --> STDERR["⚠️ stderr (2)\nStandard Error\n→ Screen or redirect"]

    style STDIN fill:#2d3748,stroke:#63b3ed,stroke-width:2px,color:#fff
    style PROCESS fill:#d69e2e,stroke:#cbd5e0,stroke-width:2px,color:#000
    style STDOUT fill:#2d3748,stroke:#68d391,stroke-width:2px,color:#fff
    style STDERR fill:#2d3748,stroke:#fc8181,stroke-width:2px,color:#fff
Stream Number Default What Goes Here
stdin 0 Keyboard Input to commands
stdout 1 Terminal Normal output
stderr 2 Terminal Error messages

By default, stdout and stderr both print to your terminal mixed together. Redirection and pipes give you control over each stream separately.

Redirection: To and From Files🔗

Redirection changes where a stream goes — from the terminal to a file, or from a file to a command's input.

  • Output Redirection (>)

    Why it matters: Capture command output to a file for logging, later processing, or sharing with others.

    Redirect stdout to a File
    ls -lh /var/log/ > filelist.txt   # (1)!
df -h > disk-report.txt
    1. Create or overwrite the file.

    > Overwrites Without Warning

    > will silently overwrite an existing file. There's no confirmation. If report.txt existed, it's gone.

    To protect against this in interactive sessions:

    Prevent Overwrite with noclobber
    set -o noclobber    # (1)!
ls > existing.txt   # (2)!
ls >| existing.txt  # (3)!

    1. Add this to ~/.bashrc.
    2. Now fails with "cannot overwrite existing file".
    3. Force the overwrite when noclobber is set.

  • Append Redirection (>>)

    Why it matters: Add to an existing file without overwriting it. The essential operator for log files and accumulating data.

    Append to a File
    echo "Deployment started at $(date)" >> deploy.log
df -h >> disk-history.txt   # (1)!

echo "=== $(date) ===" >> report.txt   # (2)!
uptime >> report.txt
free -h >> report.txt
df -h >> report.txt
    1. Build a history over time.
    2. Run multiple commands and collect all their output into one report.

  • Input Redirection (<)

    Why it matters: Feed a file into a command's stdin instead of typing. Less common in interactive use, but appears in scripts.

    Redirect File to stdin
    sort < names.txt                     # (1)!
wc -l < access.log                   # (2)!
mysql -u root -p mydb < schema.sql   # (3)!
    1. Sort the contents of names.txt.
    2. Count lines in access.log.
    3. Feed SQL to mysql.

  • stderr Redirection (2>)

    Why it matters: Error messages and normal output are separate streams. When you redirect with >, errors still print to the terminal. Use 2> to capture them separately.

    Redirect stderr
    find / -name "hosts" 2>/dev/null      # (1)!
find / -name "hosts" 2>errors.txt     # (2)!
command > output.txt 2> errors.txt    # (3)!
command > all.txt 2>&1                # (4)!
    1. Discard errors, keep results.
    2. Save errors to a file.
    3. Separate stdout and stderr into different files.
    4. 2>&1 redirects stderr (2) to wherever stdout (1) is currently going. Order matters: > all.txt 2>&1 works; 2>&1 > all.txt does not (the latter redirects stderr to the terminal, then redirects stdout to the file).

Combining Redirections🔗

Real scripts rarely use just one redirect operator — output, errors, and a live view on screen usually need to be handled together in the same command:

Multiple Redirections in Practice
find /var/log -name "*.log" | tee found-logs.txt    # (1)!
./long-running-script.sh > results.txt 2>/dev/null  # (2)!
./deployment.sh > deploy.log 2>&1                    # (3)!
./script.sh > output.log 2> errors.log               # (4)!
  1. Capture output to a file and show it on screen at once — tee reads stdin and writes to both stdout and a file.
  2. Run a long job, save the output, discard errors.
  3. Save both stdout and stderr to the same file.
  4. Save stderr to one file, stdout to another.

Here Documents and Here Strings🔗

Provisioning scripts often need to drop a complete config file onto a server — an nginx vhost, a systemd unit, a database config — without shipping a separate template alongside the script. A chain of echo "..." >> file lines works but is painful to write and edit. A here document embeds the whole file inline instead, right in the script that generates it:

Here Documents
cat << EOF > /etc/myapp/config.conf
[database]
host = db-prod-01
port = 5432
name = myapp_db
EOF

sudo tee /etc/nginx/sites-available/myapp << EOF
server {
    listen 80;
    server_name myapp.example.com;
    root /var/www/myapp;
}
EOF

Everything between << EOF and the matching EOF on its own line becomes the command's stdin. The first example writes a config file directly with cat; the second pipes the same trick through sudo tee — the standard way to write a file that needs elevated permissions from inside a script, since sudo cat << EOF > file doesn't work (the redirect runs as your user, not root).

For a single line instead of a whole file, echo "text" | command works but spins up an extra process just to hand off one string. A here string (<<<) skips that process — most useful for piping a variable's value straight into a command that only reads from stdin:

Here String (<<<)
grep "pattern" <<< "string to search in"   # (1)!
base64 <<< "$TOKEN"                         # (2)!
  1. Feed a single string straight to stdin — no file, no multi-line EOF block needed for one line.
  2. The most common real use: feed a variable's value to a command that only reads from stdin, base64 here, but the same trick works for anything.

Pipes: Command to Command🔗

A pipe (|) takes the stdout of the left command and feeds it as stdin to the right command. No intermediate file, no waiting — it's streaming.

Your First Pipeline
ls -lh /var/log/ | less   # (1)!
  1. ls produces the directory listing, the pipe (|) sends it to less, and less lets you scroll through it.

Building Pipelines🔗

Pipelines chain as many commands as you need:

Growing a Pipeline
cat /var/log/nginx/access.log # (1)!
cat /var/log/nginx/access.log | grep " 500 " # (2)!
cat /var/log/nginx/access.log | grep " 500 " | awk '{print $1}' # (3)!
cat /var/log/nginx/access.log | grep " 500 " | awk '{print $1}' | sort # (4)!
cat /var/log/nginx/access.log | grep " 500 " | awk '{print $1}' | sort | uniq -c # (5)!
cat /var/log/nginx/access.log | grep " 500 " | awk '{print $1}' | sort | uniq -c | sort -nr # (6)!
cat /var/log/nginx/access.log | grep " 500 " | awk '{print $1}' | sort | uniq -c | sort -nr | head -10 # (7)!
  1. Start simple — dump the whole access log.
  2. Filter to 500 errors only.
  3. Extract just the IP addresses.
  4. Sort them.
  5. Count occurrences of each IP.
  6. Sort by count, most first.
  7. Show only the top 10.

Filtering an access log for 500 errors, then extracting, sorting, and counting the offending IP addresses

This is how investigation pipelines get built — one stage at a time, checking the output at each step.

The Essential Pipeline Tools🔗

These commands exist primarily to work within pipelines. Several of them look interchangeable at a glance — the table below is the fast way to pick the right one before the cards go into detail on each:

You need to... Reach for
Keep only lines matching a pattern grep
Discard lines matching a pattern grep -v
Put lines in order sort
Collapse duplicates, or count them sort \| uniq -c
Pull out a column, simple fixed delimiter, no logic cut
Pull out or transform a column with any real logic awk
Find-and-replace text in a stream sed
Count lines, words, or bytes wc
Save to a file and keep piping tee
See only the first or last N lines head / tail

Filter a stream to only lines matching a pattern. Covered in depth in the grep article.

grep in Pipelines
journalctl | grep "Failed"
ps aux | grep nginx
cat /etc/passwd | grep -v "nologin"    # (1)!
  1. Exclude service accounts.

Sort lines alphabetically or numerically.

sort in Pipelines
cat names.txt | sort              # (1)!
du -sh /var/* | sort -hr          # (2)!
cat numbers.txt | sort -n         # (3)!
cat file.txt | sort -u            # (4)!
  1. Alphabetical.
  2. Human-readable sizes, largest first.
  3. Numeric sort.
  4. Sort and remove duplicates.

Remove consecutive duplicate lines, or count their occurrences. Works best after sort.

uniq in Pipelines
cat file.txt | sort | uniq               # (1)!
cat file.txt | sort | uniq -c            # (2)!
cat file.txt | sort | uniq -d            # (3)!
  1. Unique lines only.
  2. Count occurrences.
  3. Only lines that appear more than once.

Count lines, words, or characters.

wc in Pipelines
ls /etc | wc -l                      # (1)!
cat access.log | grep "404" | wc -l  # (2)!
cat file.txt | wc -c                 # (3)!
  1. How many files in /etc?
  2. How many 404 errors?
  3. How many bytes?

The four tools above filter, sort, dedupe, and count. Five more round out the toolkit — for reshaping, rewriting, and duplicating a stream, rather than narrowing it down:

Extract specific columns from structured text, with the power to filter, compute, or reformat as it goes. Reach for awk over cut the moment you need more than plain column selection.

awk in Pipelines
ps aux | awk '{print $1, $2}'                # (1)!
df -h | awk '{print $1, $5}'                 # (2)!
cat /etc/passwd | awk -F: '{print $1, $3}'   # (3)!
  1. Print the user and PID columns.
  2. Filesystem and usage %.
  3. Username and UID.

Rewrite text in a stream: substitute, delete, or print specific lines, without opening a file in an editor.

sed in Pipelines
cat nginx.conf | sed 's/8080/9090/'   # (1)!
journalctl | sed -n '10,20p'          # (2)!
cat access.log | sed '/^#/d'          # (3)!
  1. Replace the first 8080 with 9090 on each line.
  2. Print only lines 10 through 20 — -n suppresses default output, p prints the match.
  3. Delete lines starting with # (comments).

Extract specific columns or character positions from fixed-format output — simpler and faster than awk when the delimiter is consistent and you don't need any logic beyond selection.

cut in Pipelines
cat /etc/passwd | cut -d: -f1     # (1)!
cat /etc/passwd | cut -d: -f1,3   # (2)!
ls -l | cut -c1-10                # (3)!
  1. Extract the first field (username).
  2. Username and UID.
  3. First 10 characters of each line.

Write to a file AND pass through to the next pipe. Essential when you want to save intermediate results.

tee in Pipelines
find /var/log -name "*.log" | tee found-logs.txt | wc -l   # (1)!
command | tee output.txt | grep "ERROR"                    # (2)!
  1. Saves the file list AND prints the count.
  2. Saves everything to output.txt, passes only errors downstream.

Take only the first or last N lines. Ubiquitous at the end of pipelines.

head and tail in Pipelines
ps aux | sort -k3 -nr | head -5      # (1)!
ls -lt /var/log/ | head -10          # (2)!
cat access.log | tail -100           # (3)!
  1. Top 5 CPU consumers.
  2. 10 most recently modified logs.
  3. Last 100 lines.

awk and sed Are Their Own Languages

Everything shown for awk and sed above is the pipeline-scale slice — one-liners that solve one problem inline. Both are actually complete, standalone scripting languages: awk has variables, functions, and control flow built around a "pattern → action" model, and sed has its own addressing and command syntax for editing files in scripts (-i for in-place edits, branching, hold space). Whole books exist on each — sed & awk (Dougherty & Robbins) and The AWK Programming Language (Aho, Kernighan, Weinberger) — because both go far deeper than "extract a column" or "swap a string." Reach for that depth once a one-liner stops being enough.

stderr in Pipelines🔗

A critical detail: pipes only carry stdout. stderr bypasses the pipe and goes directly to the terminal.

Stderr Bypasses Pipes
find / -name "*.conf" | wc -l   # (1)!
  1. Errors print to the screen; only successful results go to wc.

To include stderr in a pipeline:

Including stderr in Pipelines
find / -name "*.conf" 2>&1 | wc -l          # (1)!
find / -name "*.conf" 2>/dev/null | wc -l   # (2)!
  1. Count everything, including error lines.
  2. Suppress errors, count only results.

Real-World Pipeline Patterns🔗

Individually, each tool above does one small thing. Chained together during a real incident, they answer specific questions fast — four of the most common ones:

Find the most common errors in the past hour:

Log Analysis Pipeline
grep " 404 " /var/log/nginx/access.log \
  | awk '{print $1}' \
  | sort | uniq -c \
  | sort -nr \
  | head -10                              # (1)!

journalctl --since "24 hours ago" --until now \
  | grep -i "error" \
  | awk '{print $1, $2, substr($3,1,2)}' \
  | sort | uniq -c                        # (2)!
  1. What IP addresses are causing the most 404s?
  2. How many errors per hour in the last day?

Find what's consuming resources:

Process Investigation Pipeline
ps aux --sort=-%mem | head -6   # (1)!

ps aux | grep "^www-data"       # (2)!

ss -tlnp | grep ":8080"         # (3)!

ss -s | grep "TCP:"             # (4)!
  1. Top 5 memory consumers (human-readable).
  2. All processes owned by www-data.
  3. Find processes listening on a port.
  4. How many connections per state?

Find what's eating disk:

Disk Analysis Pipeline
du -sh /var/* 2>/dev/null | sort -hr | head -10   # (1)!

find / -type f -size +100M 2>/dev/null \
  | xargs ls -lh 2>/dev/null \
  | sort -k5 -hr \
  | head -10                                      # (2)!

find /var/log -name "*.log" -newer /var/log -type f \
  | xargs ls -lh 2>/dev/null \
  | sort -k5 -hr                                   # (3)!
  1. Largest directories in /var.
  2. Largest files anywhere on the system.
  3. Which log files grew today?

Process configuration files:

Config Processing Pipeline
grep -v "^#" /etc/ssh/sshd_config | grep -v "^$"   # (1)!

grep -v "^#" /etc/ssh/sshd_config \
  | grep -v "^$" \
  | awk '{print $1}' \
  | sort -u                                         # (2)!

grep -v "^#" /etc/ssh/sshd_config | grep "PermitRootLogin"   # (3)!
  1. Find all uncommented settings in a config file.
  2. Find all unique setting names.
  3. Check if a setting is enabled.

Quick Reference🔗

Redirection Operators🔗

Operator What It Does Example
> Redirect stdout to file (overwrite) ls > files.txt
>> Redirect stdout to file (append) echo "line" >> log.txt
< Redirect file to stdin sort < names.txt
2> Redirect stderr to file find / 2>/dev/null
2>&1 Redirect stderr to stdout command > all.txt 2>&1
&> Redirect both stdout and stderr command &> all.txt
\| Pipe stdout to next command ls \| grep ".conf"
\| tee Write to file and pass through cmd \| tee file.txt \| wc -l

Pipeline Toolkit🔗

Command What It Does in Pipelines
grep pattern Keep only lines matching pattern
grep -v pattern Remove lines matching pattern
sort Sort lines alphabetically
sort -n Sort numerically
sort -hr Sort human-readable sizes, largest first
uniq Remove consecutive duplicates
uniq -c Count occurrences
wc -l Count lines
head -N Keep first N lines
tail -N Keep last N lines
awk '{print $N}' Extract Nth field
sed 's/x/y/' Find and replace text
cut -d: -f1 Extract field by delimiter
tee file.txt Write to file and pass through

Practice Exercises🔗

Exercise 1: Build a Log Analysis Pipeline

Using /var/log/auth.log (or /var/log/secure on RHEL), build a pipeline that:

  1. Shows only lines containing "Failed"
  2. Extracts the source IP address (the IP after "from" in the line)
  3. Counts how many failed attempts per IP
  4. Sorts by count, highest first
  5. Shows the top 5 offenders
Solution
Log Analysis Pipeline
grep "Failed" /var/log/auth.log \
  | awk '/from/{print $(NF-3)}' \
  | sort \
  | uniq -c \
  | sort -nr \
  | head -5

The awk pattern prints the field 3 from the end (NF-3) — on typical auth.log "Failed password" lines, this is the IP address.

Exercise 2: Redirect and Tee

Run a disk space analysis (du -sh /var/* 2>/dev/null) that:

  1. Saves the complete output to /tmp/disk-report.txt
  2. Simultaneously shows only entries larger than 1GB on the terminal
Solution
tee with Filtering
du -sh /var/* 2>/dev/null | tee /tmp/disk-report.txt | grep "^[0-9]*G"

tee saves everything to the file; the pipe after tee sends the same data to grep, which filters for lines starting with a size in gigabytes.

Exercise 3: Separate stdout and stderr

Run find / -name "sshd_config" and:

  1. Save only the successful results (stdout) to /tmp/found.txt
  2. Discard all "Permission denied" errors (stderr)
  3. Print the count of found files to the terminal
Solution
Separate Streams
find / -name "sshd_config" 2>/dev/null > /tmp/found.txt
wc -l < /tmp/found.txt

find / -name "sshd_config" 2>/dev/null | tee /tmp/found.txt | wc -l   # (1)!
  1. Or do it in one pipeline — tee saves the results while wc -l counts them.

That ten-minute investigation from the opening — cat | grep | awk | sort | uniq -c | sort -nr | head — is nothing more than the two ideas in this article, chained: redirection controls where a stream starts or ends, and pipes control what happens to it in between. Once both are second nature, you stop looking up pipeline recipes and start building the one you need on the spot.

Quick Recap🔗

  • Three streams: stdin (0), stdout (1), stderr (2) — redirect each independently
  • > overwrites; >> appends — the most common mistake is using > when you meant >>
  • 2>/dev/null — silence errors; ubiquitous in find and other commands that hit permission-denied directories
  • 2>&1 — merge stderr into stdout; essential when capturing all output to a file
  • | pipes only stdout — to include stderr, add 2>&1 before the pipe
  • Build pipelines incrementally — add one stage at a time, verify output, then extend
  • Core toolkit: grep, sort, uniq -c, wc -l, head, tail, awk, sed, cut, tee

What's Next?🔗

Pipes flow data between commands, and the most common thing you'll do with that data is search it. grep is the workhorse of Linux text processing — and it deserves its own deep dive.

Head to grep to learn regular expressions, recursive searching, context flags, and the patterns that turn grep from a simple filter into a powerful investigation tool.

If you're following the Debugging With Nothing But a Terminal pathway, that's the same next step.

Further Reading🔗

Command References🔗

  • man bash — the "Redirection" section covers every redirect operator
  • man tee — the tee command in detail
  • man awk — the full awk reference (also man gawk for GNU awk)
  • man sort — sort options including locale-aware and stable sorting
  • man uniq — uniq options

Deep Dives🔗

Official Documentation🔗
